Sep 21 Decided remove the woofer to check.
Creative GigaWorks S750 Manual
Connect to the line output of a Jukebox, MD Player and other portable audio devices. I started troubleshooting it and found out a “blown” capacitor, at position C62, the electrolytic capacitor that was covered inside a black insulation.
Again, these capacitors were also oversized too wide. Caps are relatively inexpensive and replacing them will eliminate present and future problems. I replaced that cap also when I replaced all of them on that board, and when I started up the green light was lit and no blinking.
CREATIVE GIGAWORKS S MANUAL Pdf Download.
I believe you said that the green power light on the main power supply stays on steady, when you turn on the audio control do you hear the start relay turn on? I will give you the exact digi-key order number if you want.
Aug 26 Also note there were still degraded glue remaining as well. Don’t show me this message again. Controleer uw email en volg de aanwijzingen op om uw inschrijving definitief te maken. You may want to replace the electrolytic that got zapped with a high temp ceramic as I believe Lex suggested, and may have been the cause of the problem because it is so clse to the heat sink.
Creative GigaWorks S speaker repair
Our goal is to provide you with a quick access to the content of the user manual for Creative GigaWorks S It sounds like you are off to a good start. In Post I pasted part of a schematic I found for the S The T2 info should be on the transformer itself.
freative
Should be only a single click when pressing the power on from the control pod. Notice those disc-shaped ceramic capacitors besides them?
English als creativf per email. Two specific areas proved very difficult and unfortunately, the green came up with them. Wij controleren de vraag en zonodig wordt deze verwijderd. This restores normal circuit functions. The following sections contain notices for various countries:. If its a certified Y capacitor then it should be fine. Miscellaneous Noticed that the power amplifier boards has lots of el-cheapo crap capacitors as well. Suspect the filter cap on the audio board which I did not replace mfd vbut have not replaced it yet.
First, check what was the voltage output at the main power section for the power amplifier section.
Audio control pod and remote control – CREATIVE GigaWorks S750 User Manual
D22, D23, D24 and D25 are actually a 15V zener diode. The glue remains white in color thus had not degraded mwnual possibly a different glue than the one used on the power supply board. Please see below some images: Feb 12 I will be very careful when dealing with electricity.
It can handle the soldering, but I feel out of my depth working out what is wrong i.
I just checked the stock caps Dreative pulled out, found out that almost every copper tubes inside through holes have also been pulled out with caps leads.
This speaker system uses a triple voice coil woofer!
It is not possible to know whether or not heat was a factor, I rather doubt it. Rceative hot air treatment is not recommended at all, and will eventually kill the subwoofer which is what happened to the original person who posted that “quick fix”, his subwoofer finally went kaput.
U kunt hieronder aangeven waarom deze vraag ongepast is. No blown balloon capacitors. By the way, what was wrong with it?
